50 Ohm coaxial cable
RG58 coaxial cable
| Spec. | Rg58/u | Rg58 a/u | Rg58 c/u | |
| Conductor | Material | Bc/Tc | Bc/Tc | Bc/Tc |
| Normal.Diameter | 19awg | 19*0.2mm | 19*0.18mm | |
| Insulation | Material | PE | Foam PE | PE |
| Normal.Diameter | 2.95mm | 2.90mm | 2.95mm | |
| Shield | Material | Bc/Tc Braiding | Bc/Tc Braiding | Bc/Tc Braiding |
| Coverage | 0.95 | 0.95 | 0.95 | |
| Jacket | Material | PVC/PE | PVC/PE | PVC/PE |
| Normal.Thick. | 0.80mm | 0.80mm | 0.80mm | |
| Normal.Diameter | 4.95mm | 4.90mm | 5.08mm | |
RG8/RG 213/RG214/RG174 coaxial cable
| Spec. | RG8 | RG213 | RG214 | RG174 | |
Conductor | Material | Bc | Bc | Tin copper | Bc/Ccs |
| Normal.Diameter | 10awg(2.59mm) | 13awg/7*0.75mm | 13awg/7*0.75mm | 7*0.16mm(0.48mm) | |
| Material | Foam PE | PE | Foam PE | PE | |
Insulation | Normal.Diameter | 7.25mm | 7.24mm | 7.25mm | 1.60mm |
| Material | Al Foil+Tc Braiding | Bc Braiding | Tc Braiding | Tc Braiding | |
Shield | Coverage | 35%-75% | 96% | 96%-98% | 90% |
| Material | PVC/PE | PVC/PE | PVC/PE | PVC | |
Jacket | Normal.Thick. | ≥1.0mm | ≥1.0mm | ≥1.0mm | 0.5mm |
| Normal.Diameter | 10.24mm | 10.30±0.10mm | 10.80±0.10mm | 2.7±0.10mm | |
